Msi PRO B650M-A WIFI AM5 Micro-ATX Motherboard, AMD B650 Chipset, 4 x 2-Channel DDR5 Slots, 128GB Max Memory, Wi-Fi 6E, 2x PCI-E x16, 2x M.2, 1x HDMI, 1x DP, USB 23.2/2.0

Msi PRO B650M-A WIFI AM5 Micro-ATX Motherboard, AMD B650 Chipset, 4 x 2-Channel DDR5 Slots, 128GB Max Memory, Wi-Fi 6E, 2x PCI-E x16, 2x M.2, 1x HDMI, 1x DP, USB 23.2/2.0

79.900 BHD
79.900 BHD
Sale Sold out
Tax included.
Chipset AMD B650
CPU Support Supports AMD Ryzen™ 8000/7000 Series Desktop Processors, Socket AM5
Memory
  • 4x DDR5, Maximum Memory Capacity 256GB
  • Memory Support DDR5 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz
  • Max. overclocking frequency:
    • 1DPC 1R Max speed up to 7200+ MHz
    • 1DPC 2R Max speed up to 6000+ MHz
    • 2DPC 1R Max speed up to 6000+ MHz
    • 2DPC 2R Max speed up to 5400+ MHz
  • Supports Dual-Channel mode
  • Supports non-ECC, un-buffered memory
  • Supports AMD EXPO
Onboard Graphics
  • 1x HDMI™ - Supports HDMITM 2.1, maximum resolution of 4K 60Hz*
  • 1x DisplayPort - Supports DP1.4, maximum resolution of 4K 60Hz*

*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Slot
  • 2x PCI-E x16 slot
    • Supports x16/x4 (For Ryzen™ 7000 Series processors)
    • Supports x8/x4 (For Ryzen™ 7 8700G and Ryzen™ 5 8600G processors)
    • Supports x4/x4 (For Ryzen™ 5 8500G processor)
  • 1x PCI-E x1 slot
    • PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
    • PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
    • PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
Storage
  • 2x M.2 - M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices - M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
  • 4x SATA 6G - M2_2 supports PCIe 4.0 x2 speed when Ryzen™ 5 8500G is installed
RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices - Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
LAN Realtek® 8125BG 2.5G LAN
Wireless LAN & Bluetooth
  • AMD Wi-Fi 6E - The Wireless module is pre-installed in the M.2 (Key-E) slot - Supports MU-MIMO TX/RX - Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/5GHz or 6GHz* bands
  • Supports 802.11 a/b/g/n/ac/ax
  • Supports Bluetooth® 5.3**

* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.

** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
Audio Realtek® ALC897 Codec - 7.1-Channel High Definition Audio - Supports S/PDIF output
Internal IO
  • 1x Power Connector(ATX_PWR)
  • 2x Power Connector(CPU_PWR)
  • 1x CPU Fan
  • 1x Pump Fan
  • 3x System Fan
  • 2x Front Panel (JFP)
  • 1x Chassis Intrusion (JCI)
  • 1x Front Audio (JAUD)
  • 1x Com Port (JCOM)
  • 1x Tuning Controller connector(JDASH)
  • 2x Addressable V2 RGB LED connector (JARGB_V2)
  • 2x RGB LED connector(JRGB)
  • 1x TPM pin header(Support TPM 2.0)
  • 4x USB 2.0 ports
  • 2x USB 3.2 Gen1 Type A ports
  • 1x USB 3.2 Gen2 Type C ports
